Preliminary Technical Information
Linear Power MOSFET IXTK46N50L
With Extended FBSOA IXTX46N50L
N-Channel Enhancement Mode
V DSS
I D25
R DS(on)
= 500
= 46
≤ 0.16
V
A
Ω
TO-264 (IXTK)
Symbol
Test Conditions
Maximum Ratings
V DSS
T J = 25 ° C to 150 ° C
500
V
V DGR
T J = 25 ° C to 150 ° C; R GS = 1 M Ω
500
V
G
V GS
V GSM
Continuous
Transient
± 30
± 40
V
V
D
S
(TAB)
I D25
I DM
I AR
E AR
E AS
P D
T J
T C = 25 ° C
T C = 25 ° C, pulse width limited by T JM
T C = 25 ° C
T C = 25 ° C
T C = 25 ° C
46
100
46
60
1.5
700
-55 to +150
A
A
A
mJ
J
W
° C
PLUS247 (IXTX)
TAB
T JM
T stg
T L
T SOLD
1.6 mm (0.063 in) from case for 10 s
Plastic body for 10 s
150
-55 to +150
300
260
° C
° C
° C
° C
G = Gate
S = Source
D = Drain
TAB = Drain
M d
F c
Mounting torque
Mounting force
(TO-264)
(PLUS247 TM )
1.13/10 Nm/lb.in.
20...120/4.5...27 N/lb.
Features
Weight
PLUS247
TO-264
6
10
g
g
Designed for linear operation
International standard package
Unclamped Inductive switching (UIS)
rated
Molding epoxies meet UL 94 V-0
flammability classification
Symbol
Test Conditions
Characteristic Values
(T J = 25 ° C, unless otherwise specified)
Min. Typ. Max.
Applications
Programmable loads
BV DSS
V GS(th)
I GSS
V GS = 0 V, I D = 1 mA
V DS = V GS , I D = 250 μ A
V GS = ± 30 V, V DS = 0 V
500
3
6
± 200
V
V
nA
Current regulators
DC-DC converters
Battery chargers
I DSS
R DS(on)
V DS = V DSS T J = 25 ° C
V GS = 0 V T J = 125 ° C
V GS = 20 V, I D = 0.5 I D25 , Note 1
50
1
0.16
μ A
mA
Ω
DC choppers
Temperature and lighting controls
Advantages
Easy to mount
Space savings
High power density
IXYS reserves the right to change limits, test conditions, and dimensions.
? 2007 IXYS CORPORATION, All rights reserved
DS99350A(03/07)
